Key Features

True

Accuracy

Using Terrain Compensation and GPS with WAAS, EGNOS and GLONASS to obtain a true ground position, even on rolling ground.

Autonomous Mode

The Stealth is capable of working without a display, providing recording and control without operator input.

Product

Controller

With an array of control and sensor input / outputs the Stealth can be fitted to completely control Spreaders, Sprayers and Planters



Buy Now



GPS Guidance / Product Control

from only

£2,000+vat

Product Specification

Android Tablet

  • Bright 7” LCD Display

  • High accuracy, durable touch screen

  • Micro SD storage card slot

  • Rechargeable battery (via USB)

  • WiFi (802.11 b/g/n) and Bluetooth connectivity

  • Optional 8" Waterproof tablet upgrade

Stealth Hardware
  • 10hz GPS receiver (WAAS, EGNOS and GLONASS)

  • Built-in Terrain Compensation

  • Bluetooth (2.0) connectivity

  • Optional Internal Modem

  • USB port for charging device

  • Communication Ports :- 2x Can, 2x RS232, 1x USB

  • Control I/O :- 2x PWM, 5x Internal Relay, 2x Motor Controller

  • Sensor I/O :- 1x Pulse, 6x Switch, 1x Current, 2x Analogue 0-15v

Guidance and Recording APP
  • Field Area Measurement

  • Straight and Curved 3D Guidance modes

  • Field recognition

  • Headland Guidance

  • Job Recording

  • Pause / Resume job

  • Headland Warning

  • Data Sync and Tracking (3G or WiFi)

  • Software upgrades :- Variable Rate, Section Control, Auto Shut Off, Headland Control, Product Control

Product Control APP

  • Flow Measurement

  • Flow Control

  • Actuator Control

  • Belt Control

  • Software upgrades :- Variable Rate, Section Control, Auto Shut Off, Headland Control, Guidance and Recording



Upgrade Options

The following upgrade options are unique to the BlackBox Marine and Stealth, for general upgrade options click here

GPS Options

Optional GPS upgrades on both the Marine and Stealth providing GPS coverage in areas with no differential service e.g. Southern Hemisphere.

Single Product Control Node

Using the BlackBox CAN interface on either the BlackBox Marine or BlackBox Stealth, the Single Product Control Node adds more connectivity for product control.

Up to 10 boom sections can be controlled automatically via Section Control.

With the BlackBox Stealth a maximum of 8 nodes can be connected providing a limit of up to 80 boom sections per Stealth installation.

With each Control Node, a single product applicator can be controlled via motor control or PWM hydraulic control.

Switch Box

Both the BlackBox Marine and the BlackBox Stealth have direct switch inputs for master switch and boom switch controls.

For users who require a separate switch box, the Patchwork Switch Box provides up to 10 individual boom switch control with 3 position switches, allowing for section to be switched OFF, ON or switched to Automatic Section Control. With a power switch and master switch the Switch Box provides maximum control to the operator.

With the BlackBox Stealth multiple Switch Boxes can be connected to provide manual control for up to 80 boom sections.

The power switch can be wired to power up/down all of the BlackBox devices.
